Nuxt 4 + Three.js WebGPU: Ship a Next‑Gen 3D Scene with WebGL Fallback
Build a WebGPU‑powered Three.js scene in Nuxt 4 with a clean WebGL fallback, using TypeScript and client‑only hydration.
Tags: Nuxt 4, Three.js, WebGPU, TypeScript
Time to read: 8 min
Note: Three.js’ WebGPURenderer is available in modern Chromium‑based browsers and Safari TP when WebGPU is enabled. This tutorial detects support at runtime and falls back to WebGL seamlessly.
Prerequisites
- Familiarity with the command line
- Node.js 18+ installed
- A modern browser (Chrome/Edge 113+, or Safari TP) for WebGPU
- Optional: Basic Three.js knowledge
Create a Nuxt 4 app
npx nuxi init nuxt4-webgpu
cd nuxt4-webgpu
npm install
Run the dev server to verify:
npm run dev
Visit http://localhost:3000
Install Three.js
npm i three
We’ll dynamically import the WebGPU renderer only on the client to keep SSR happy and bundles lean.
Add a client‑only Three.js component
Create a client‑only component so Three.js runs only in the browser.
File: components/ThreeWebGPUScene.client.vue
<script setup lang="ts">
import { onMounted, onBeforeUnmount, ref } from 'vue';
// Types shared by WebGL/WebGPU
type AnyRenderer = any; // keep loose to unify WebGLRenderer/WebGPURenderer APIs
const canvasEl = ref<HTMLCanvasElement | null>(null);
onMounted(async () => {
const THREE = await import('three');
const { OrbitControls } = await import('three/examples/jsm/controls/OrbitControls.js');
// Prefer WebGPU if available, otherwise WebGL
let renderer: AnyRenderer;
const hasWebGPU = typeof navigator !== 'undefined' && 'gpu' in navigator;
if (hasWebGPU) {
try {
const { WebGPURenderer } = await import('three/examples/jsm/renderers/WebGPURenderer.js');
renderer = new WebGPURenderer({
canvas: canvasEl.value!,
antialias: true,
alpha: true,
powerPreference: 'high-performance'
});
// WebGPU renderer requires explicit init
await renderer.init();
} catch (e) {
// Fallback to WebGL if WebGPU init fails
renderer = new THREE.WebGLRenderer({
canvas: canvasEl.value!,
antialias: true,
alpha: true,
powerPreference: 'high-performance'
});
}
} else {
renderer = new THREE.WebGLRenderer({
canvas: canvasEl.value!,
antialias: true,
alpha: true,
powerPreference: 'high-performance'
});
}
// Common renderer settings
renderer.setPixelRatio(Math.min(window.devicePixelRatio, 2));
renderer.setSize(window.innerWidth, window.innerHeight);
renderer.toneMapping = THREE.ACESFilmicToneMapping;
renderer.toneMappingExposure = 1.0;
renderer.outputColorSpace = THREE.SRGBColorSpace;
// Scene setup
const scene = new THREE.Scene();
scene.background = new THREE.Color('#0b1020');
const camera = new THREE.PerspectiveCamera(
60,
window.innerWidth / window.innerHeight,
0.1,
100
);
camera.position.set(3, 2, 5);
const controls = new OrbitControls(camera, canvasEl.value!);
controls.enableDamping = true;
// Lights
const ambient = new THREE.AmbientLight(0xffffff, 0.5);
const dir = new THREE.DirectionalLight(0xffffff, 1.2);
dir.position.set(5, 8, 3);
scene.add(ambient, dir);
// Geometry: a glossy torus knot + a floor
const knotGeo = new THREE.TorusKnotGeometry(1, 0.35, 256, 64);
const knotMat = new THREE.MeshStandardMaterial({
color: 0x88ccff,
metalness: 0.8,
roughness: 0.3
});
const knot = new THREE.Mesh(knotGeo, knotMat);
knot.castShadow = false;
knot.receiveShadow = false;
scene.add(knot);
const floorGeo = new THREE.PlaneGeometry(20, 20);
const floorMat = new THREE.MeshStandardMaterial({
color: 0x0f162e,
metalness: 0.2,
roughness: 0.9
});
const floor = new THREE.Mesh(floorGeo, floorMat);
floor.rotation.x = -Math.PI / 2;
floor.position.y = -1.5;
scene.add(floor);
// Subtle sky fill via a big hemisphere gradient mesh (works in WebGL/WebGPU)
const hemiGeo = new THREE.SphereGeometry(50, 32, 16);
const hemiMat = new THREE.MeshBasicMaterial({ color: 0x0b1020, side: THREE.BackSide });
const hemi = new THREE.Mesh(hemiGeo, hemiMat);
scene.add(hemi);
const clock = new THREE.Clock();
function onResize() {
const w = window.innerWidth;
const h = window.innerHeight;
renderer.setSize(w, h);
camera.aspect = w / h;
camera.updateProjectionMatrix();
}
window.addEventListener('resize', onResize);
// Animation loop (supported by both WebGLRenderer and WebGPURenderer)
const loop = () => {
const dt = clock.getDelta();
controls.update();
knot.rotation.x += 0.4 * dt;
knot.rotation.y += 0.25 * dt;
renderer.render(scene, camera);
};
renderer.setAnimationLoop(loop);
onBeforeUnmount(() => {
renderer.setAnimationLoop(null as unknown as FrameRequestCallback);
window.removeEventListener('resize', onResize);
controls.dispose();
knotGeo.dispose();
knotMat.dispose();
floorGeo.dispose();
floorMat.dispose();
hemiGeo.dispose();
hemiMat.dispose();
renderer.dispose?.();
});
});
</script>
<template>
<canvas ref="canvasEl" class="webgpu-canvas" />
</template>
<style scoped>
.webgpu-canvas {
position: fixed;
inset: 0;
width: 100vw;
height: 100vh;
display: block;
background: #0b1020;
}
</style>
Notes:
- The .client.vue suffix ensures the component renders only in the browser, avoiding SSR issues.
- We check navigator.gpu to prefer WebGPU and gracefully fall back to WebGL.
- renderer.init() is required for WebGPURenderer and is a no‑op for WebGL.
Add a page to mount the scene
File: pages/index.vue
<script setup lang="ts">
</script>
<template>
<div>
<ThreeWebGPUScene />
<div class="overlay">
<h1>Nuxt 4 + Three.js WebGPU</h1>
<p>WebGPU when available, WebGL otherwise.</p>
</div>
</div>
</template>
<style scoped>
.overlay {
position: fixed;
left: 24px;
bottom: 24px;
color: #c9d4ff;
background: color-mix(in oklab, #0b1020 80%, transparent);
border: 1px solid #253058;
border-radius: 12px;
padding: 12px 16px;
backdrop-filter: blur(6px);
font-family: ui-sans-serif, system-ui, -apple-system, Segoe UI, Roboto, sans-serif;
}
.overlay h1 {
font-size: 18px;
margin: 0 0 6px;
}
.overlay p {
margin: 0;
opacity: 0.9;
}
</style>
TypeScript tips (optional)
No extra tsconfig is required for this setup. If your linter complains about the AnyRenderer union, you can introduce a minimal type:
File: types/three-webgpu.d.ts
declare module 'three/examples/jsm/renderers/WebGPURenderer.js' {
import { WebGLRendererParameters, ColorSpace, ToneMapping } from 'three';
export class WebGPURenderer {
constructor(params?: WebGLRendererParameters & { canvas?: HTMLCanvasElement });
init(): Promise<void>;
setSize(w: number, h: number): void;
setPixelRatio(r: number): void;
setAnimationLoop(cb: FrameRequestCallback | null): void;
render(scene: any, camera: any): void;
dispose(): void;
outputColorSpace: ColorSpace;
toneMapping: ToneMapping;
toneMappingExposure: number;
}
}
Then reference types in tsconfig.json:
{
"compilerOptions": {
"types": ["@types/node"]
}
}
Nuxt automatically picks up .d.ts files in the project.
Run it
npm run dev
- If your browser supports WebGPU, the scene uses WebGPU.
- If not, it falls back to WebGL automatically.
Production build
npm run build
npm run preview
Open the preview URL and confirm the scene renders smoothly.
Troubleshooting
- Black screen in Safari: Ensure WebGPU is enabled (Develop > Experimental Features > WebGPU) or rely on the WebGL fallback.
- Type errors on imports from examples/jsm: Add the ambient .d.ts snippet above or use any in your component.
- Performance: Reduce geometry complexity (e.g., TorusKnotGeometry segments) and cap devicePixelRatio to 2 as shown.
What’s new here?
- WebGPU in Three.js: The WebGPURenderer has matured, enabling next‑gen graphics with better performance and modern shading models in browsers that support the WebGPU API.
- Nuxt 4 client‑only hydration: Using a .client.vue component keeps SSR fast and reliable while enabling advanced browser‑only graphics.
Next steps
- Add post‑processing (Bloom/Tone mapping) via the Three.js NodeMaterial system for WebGPU.
- Replace fallback detection with a UI toggle to compare WebGPU vs WebGL.
- Stream HDRI environments and compressed meshes with KTX2 to improve visual quality and load times.
Enjoy shipping a next‑gen 3D experience with Nuxt 4 and Three.js!
